CAD/CAM for Tooling with Unrivaled Productivity

Stay competitive across your entire range of operations with integrated CAD/CAM software that delivers major advantages for mold, die, and manufacturing shops.
1

interface for CAD/CAM
70%

faster delivery time
40k+

installations worldwide

Why Cimatron?

  • Single, integrated, dedicated solution for tooling
  • Boosts productivity
  • Handles any geometry
  • Machines any part
  • Has local training and support from tooling experts
component
Cimatron overview video

What is Cimatron?

Since 1982, Cimatron® has provided toolmakers with an end-to-end solution for designing and manufacturing tools including molds, dies, and electrodes, as well as programming any CNC and EDM machine for molds, dies, plates, and discrete manufacturing. While Cimatron is at its most powerful when used as a fully-integrated system, it also provides standalone solutions for faster quoting, tool design, electrode creation, and NC programming.

  • Cimatron Mold
  • Cimatron Die
  • Cimatron Electrode
  • Cimatron NC Programming

With Cimatron software, you get one solution with a single, intuitive, easy-to-use interface for your entire workflow—from quoting, to design, to manufacturing.

Sample toolmaking workflow

Data Import
>
Quoting
>
Parting
>
Preliminary Design
>
Design
>
Drawing
>
Electrodes
>
NC Programming

What Can You Do with Cimatron?

Dramatically increase your productivity, competitiveness, and profitability with a wide range of dedicated, applicative tools for mold, die, and electrode design and manufacturing, as well as a full range of CNC technologies, from simple 2.5-axis milling and drilling to complex 5-axis machining.

  • Start working immediately with any input geometry.
  • Deliver high-quality tools of any complexity or size with superb surface quality in record time.
  • Shorten tool delivery time by up to 70 percent.
  • Realize a return on investment (ROI) in six months or less.
  • Easily handle engineering changes (ECOs).
Cimatron Mold

MOLD DESIGN AND MANUFACTURING FEATURES

Cimatron Die

DIE DESIGN AND MANUFACTURING FEATURES

Electrode Design and Manufacturing Features

ELECTRODE DESIGN AND MANUFACTURING FEATURES

NC Programming Features

NC PROGRAMMING FEATURES

What’s New in Cimatron?

Cimatron 16 offers a clean new UI and increased automation for faster mold design, electrode creation, and NC programming for toolmakers. Powerful functionality dedicated to tool making includes die addendum surfaces, mesh manipulation, and drafting detailing. Here are just a few highlights:

  • General UI Improvements
  • Tool Design and Modeling
  • Electrodes
  • Conformal Cooling
  • NC Programming Automation
  • Enhanced CAM Strategies

Find out what’s new in Cimatron 16

How Can You Buy Cimatron?

Cimatron offers three basic licensing solutions:

  • Cimatron Designer Solution: CAD-only solution provides full 3D design and modeling capabilities, as well as fully-associative 2D drawing and sketching functions.
  • Cimatron NC Solution: CAM-only solution provides complete and comprehensive milling, drilling, simulation, and verification capabilities up to 2.5 axes + 2X positioning.
  • Cimatron Master Solution: Comprehensive, integrated CAD/CAM solution includes all features of the Cimatron Designer Solution and the Cimatron NC Solution for a powerful, end-to-end solution that provides all the tools and capabilities you need for designing and manufacturing complex projects.

In addition, Cimatron offers a view-only license and special solutions and bundles for electrodes, additive molding, NC plate machining, turning, EDM setup, and education/academic institutions, plus optional add-ons for NC programming and mold, die, and electrode design and manufacturing so that you can customize your workflow.

Contact us for pricing

eBook banner image

Want to deliver high-quality molds of any complexity or size in record time?

Download eBook

Customer Stories

Officine Drag - Creative Craftsmanship

Read more

Eurominuterie SRL Creates Fashion Details with Passion

Read more

Allegiance Mold Delivers High-Quality Injection Molds Twice as Fast with Cimatron Software

Read more

Cimatron has enabled us to produce more per hour, so we can compete more effectively with companies overseas. And when it comes to the really difficult stuff, no other software can do what Cimatron can.
— Thoms LaMarca, Jr., Owner, L&Z Tool and Engineering, Inc., Watchung, New Jersey, USA

Videos

VMR Achieves Fast and Efficient Prototyping with Cimatron

VMR GmbH & Co. KG in Mönchweiler, Germany delivers 10,000 electrodes per year quickly and cost-effectively using Cimatron, reducing electrode design and manufacturing time by 70%

Liberty Molds Eliminates Errors and Reduces Design Time by 50% with Cimatron Software

Liberty Molds, Inc. and Allegiance Mold, LLC in Portage, MI use Cimatron software to design and manufacture custom, high-quality plastic injection molds faster to maintain a competitive edge.

HARTING Improves Tool Quality, Reduces Scrap, and Delivers Molds Faster with Cimatron

HARTING Applied Technologies GmbH in Espelkamp, Germany achieves data consistency throughout the entire mold-making process, from design to manufacturing, with Cimatron.

B&J Specialty Increases Production Rate by 30% with Cimatron Designed Conformally-Cooled Mold

B&J Specialty Increases Production Rate by 30% with Cimatron Designed Conformally-Cooled Injection Mold. The new conformally-cooled mold inserts reduced temperature variation throughout cooling to 18˚C and shrank cycle time on the mold from one minute to 40 seconds, an overall productivity improvement of 30 percent.

Bastech Uses Cimatron and Conformal Cooling Inserts to Reduce Costs and Time

SAVE 70% OFF DESIGN TIME, 16% OFF MOLD COST, and 14% OFF CYCLE TIME. Scott Young, Engineering Manager at Bastech, a single-source solution provider for mold design & manufacturing, and additive manufacturing services explains how the implementation of Cimatron for conformal cooling design has introduced a new level of simplicity, efficiency, and economy to mold design.

Request a Free Trial of Cimatron
